B-EP2D

We have put our big printer technology into the smallest possible package. Perfect for labelling on the shop floor, printing prescriptions on hospital wards, issuing tickets in the street or barcoding in the warehouse.

APPLICATION

RETAIL

Price mark-down and shelf-edge labelling, queue busting, promotions

WAREHOUSE AND LOGISTICS

Shipping labels, invoices, parcel tracking, delivery notes

HOSPITALITY

Event and meal tickets, mobile POS

HEALTHCARE

Mobile pharmacy, patient IDs, document and lab sample tracking

PUBLIC SERVICES

Traffic wardens, police, facilities operatives and public transport (tickets, fines, utility billing, metre reading, etc.)

FIELD SUPPORT

PAT testing, receipts for field sales and support charges.

Unit
Need help about this product? Contact Us

DURABLE AND ROBUST

"In the real world, accidents can happen, so we developed rugged rubber corners, easily passing a 1.8 m drop test on to concrete (1.5 m for B-EP4).

We didn't stop there with the rubber, we used it on the external ports to protect them from any spills. Even strict IP54 enclosure standards against dust and water ingress are surpassed with the optional carry case."

SO SIMPLE TO USE

"For user friendliness and very fast operator training times, there's nothing like the clear backlit LCD read-out on the larger Toshiba thermal printers.

So we put it into the mobile range as well, displaying a label counter, battery level, wireless signal strength and error messages. There's audible alerts too, just in case."

LESS MEDIA CHANGES

"Papers or labels dropped in with one hand? No problem.

The large capacity we've designed means changing media much less often. Plus there's no cores required on the rolls, so minimal waste.

POWER OPTIONS

"The high endurance lithium ion battery ensures many hours of operation. Swap it out for external recharging or simply charge in site using an optional adaptor.

For applications on the road there is a cigarette lighter charging adapter (12 V input) for the B-EP2 and in the warehouse, there's a DC adapter (48 V input) to charge either model in a forklift."

EASY NETWORKING

"The EP range is WiFi certified, making networking to all wireless or cabled systems a breeze.

USB 2.0 and IrDA (infrared) are standard across the EP models. Simply choose between Bluetooth, wireless LAN and serial. The serial model can be upgraded to wireless and Bluetooth."

SWIFT INTEGRATION

"The EP series speaks many programming languages and is designed to simply plug and play without any software changes, whether it's a Toshiba printer using TPCL or any make using BCI (Basic Command Interpreter).

Both models will handle inputs from other peripherals such as scales and scanners. Uniquely, they support ESC/POS language."

Programming Language Toshiba TPCL, LABEL, RECEIPT, ESC POS; Basic language for the Basic Command Interpreter (BCI)
Direct Thermal Models 203 dpi; 2"/48 mm print width
Options Batteries, single bay charger, 6 bay charger, Linerless Kit, AC power supply, DC/DC adaptor, Cigarette lighter adaptor (B-EP2 only), Sholder Strap, Carry case
Weight 480 g
Standard Connectivity GH20 model : IrDA,USB, RS232. GH32 model : IrDA,USB, Bluetooth GH40 model : IrDA,USB, Wireless LAN
Maximum Speed 4 ips (100 mm/sec)
Drop Strength 1.8 m to concrete
Dimensions (W x D x H) 87.9 x 118.9 x 65.0 mm
Max. Print Length 995 mm
IP Rating IP54 with optional carry case
